Description

Vibrating Slagging Discharge Carbon Steel Vertical Leaf Filter For Chemical Industry

Leaf filter

Leaf Filter (Blade filter) refers to the filter device suitable for the filtration and separation process of decolorized oil filtration, clarification filtration and crystal in the production of oil, chemical industry, medicine and other industries. The leaf filter (blade filter) solves the problems of difficult filtration and slag discharge of machine pressed crude oil such as cottonseed, rapeseed and castor in the oil industry.

Vibrating Slagging Discharge Carbon Steel Vertical Leaf Filter For Chemical Industry

Technical parameters

Temperature :≤ 150 ℃ Working Pressure: Rated Pressure:0.1-0.4 Mpa Max Pressure:0.5 Mpa
Filtering Area（m2)	Filtering Area（m2)	Processing Capacity (T/h)			Volume of Tank	Weight of Main Part
Filtering Area（m2)	Filtering Area（m2)	Oil	Resin	Drink	Volume of Tank	Weight of Main Part
2	30	0.4-0.6	1-1.5	1-3	120	300
4	60	0.5-1.2	2-3	2-5	250	400
7	105	1-1.8	3-6	3-6	420	600
10	150	1.6-3	5-8	5-8	800	900
12	240	2-4	6-9	6-9	1000	1100
15	300	3-5	7-12	8-11	1300	1300
20	400	4-6	9-15	12-17	1680	1700
25	500	5-7	12-19	16-21	1900	2000
30	600	6-8	14-23	19-25	2300	2500
36	720	7-9	16-27	23-30	2650	3000
40	800	8-11	21-34	30-38	3000	3300
45	900	9-13	24-39	36-44	3200	3500
52	1040	10-15	27-45	42-51	3800	4000
60	1200	11-17	30-52	48-60	4500	4500
70	1400	12-19	36-60	56-78	5800	5500
80	1600	13-21	40-68	64-78	7200	6000
90	1800	14-23	43-72	68-82	7700	6500
